E-Bikes

Don’t be fooled by this e-bike’s name, the Commute EX is just at home on those picturesque country trails as it is on the streets! Big tyres ensure a comfy ride, and a more upright position eases stress points on those long weekend jaunts, made so much easier by the large 400Wh Samsung powered battery.

• Motor: 250W 36V rear hub brushless gear drive
• Torque: 45Nm regulated to 15.5 mph
• Battery: Removable 418Wh (11.6Ah) 36v with SAMSUNG cells
• Range: 40 miles (60km) based on average conditions
• Controller: 540Wh (15Ah) 36v
• Sensor: 12 magnetic point speed sensor
• Display: 5 mode LED module with walk assist
• Charger: 2Ah 36v smart charger - 4h charge time
• Cable: Waterproof IP67 with quick connectors
• Shifters: Shimano ALTUS RapidFire Plus
• Rear Mech: Shimano ACERA 8 Speed
• Cassette: Shimano 11-30 tooth
• Chainset: Alloy 44 tooth 170mm with CNC finish
• Pedals: Alloy with non-slip sandpaper tread
• BB: Sealed cartridge
• Chain: KMC X8 anti-rust

BUILT FOR ADVENTURE, THE EXPLORE E+ TURNS COMMUTES AND ESCAPES INTO OPEN HORIZONS. WITH VERSATILE DESIGN AND SEAMLESS INTEGRATION, IT DELIVERS SMOOTH SUPPORT, CONFIDENCE, AND FREEDOM TO RIDE FARTHER—WHEREVER THE JOURNEY LEADS.

• SizesS, M, M/L, L, XL
• ColoursAlpine Green
• FrameAdvanced-grade Composite, 12x142mm thru-axle, disc
• ForkAdvanced-grade Composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
• HandlebarGiant Contact XS:38cm, S:38cm, M:40cm, M/L:40cm, L:42cm, XL:42cm
• GripsStratus Lite 2.0
• StemGiant Contact AeroLight XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
• SeatpostGiant Variant, composite, -5/+15mm offset
• SaddleGiant Approach
• PedalsPEDALS NOT SUPPLIED
• ShiftersShimano 105 Di2
• Front DerailleurShimano 105 Di2 FD-R8150
• Rear DerailleurShimano 105 Di2 RD-R8150
• BrakesShimano 105 Di2 hydraulic, Shimano RT-CL700 rotors [F]160mm, [R]140mm
• Brake LeversShimano 105 Di2
• CassetteShimano 105, 12-speed, 11x34
• ChainKMC X12L-1
• CranksetShimano 105, 36/52 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm
• Bottom BracketShimano, press fit
• RimsGiant SLR 2 40 WheelSystem, [F]40mm, [R]40mm
• Hubs[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30T pawl driver, CenterLock, 12mm thru-axle
• SpokesSapim
• TyresGiant Gavia Course 0, tubeless, 700x28c (28mm), folding

• Extrastubeless prepared, 33mm max tire size
• Max Tyre Clearance33mm
• WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Every trail, every steep climb, every thrilling descent. Nothing is out of bounds with the Reign E+. Tested and developed by Giant’s E-bike enduro pros, this proven trail ripper gives you the power to enjoy the best parts of the ride again and again.

• Motor - Giant SyncDrive Pro2 85Nm, PedalPlus 6-Sensor technology
• Controller - Giant RideControl Ergo3, grip integrated remote
• Display - Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
• Battery - Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible (exculde S size)
• Charger - Giant EnergyPak 6A smart charger, 60% in 2:15h
• Connectivity - Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
• Sizes - S, M, L, XL
• Colours - Gloss Raw Aluminium / Black
• Frame - ALUXX SL-grade aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, Universal Derailleur Hanger
• Fork - SR Suntour Durolux 38 Boost EQ, 170mm travel, 44mm offset, RC2, 15LH-110
• Shock - Fox Float Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned, recommended sag: 30%
• Handlebar - Giant Contact Trail, 35x800mm
• Grips - Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
• Stem - Giant Contact SL 35
• Seatpost - Giant Contact Switch, dropper, 30,9mm (S:125/M:150/L:170/XL:200)
• Saddle - Giant Romero Trail
• Pedals - Flatpedal
• Shifters - Shimano Cues LinkGlide 1x11
• Front Derailleur - MRP 1X HD2 custom co-molded chain guide
• Rear Derailleur - Shimano Cues LinkGlide
• Brakes - Shimano BR-MT420, 4-piston, hydraulic disc, 203mm
• Brake Levers - Shimano Deore, I-spec EV
• Cassette - Shimano Cues LinkGlide, CS-LG400-11, 11-50T, 11-speed
• Chain - Shimano LinkGlide, CN-LG500
• Crankset - Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-HD forged crankarm set (S/M:160mm, L/XL:165mm)
• Bottom Bracket - n/a
• Rims - Giant AM30, Tubeless ready, 30mm inner width, 29" [F] / 27.5" [R]
• Hubs - Shimano MT410, Boost, Center-Lock, [F] 110x15 [R] 148x12mm HG Drive Body Thru-axle
• Spokes - Sapim E-Lite [R] Race [F], e-bike optimised
• Tyres - Maxxis Minion DHF 29x2.6"" foldable, Tubeless, EXO+, 3C MaxxTerra[F] Maxxis High Roller II 27.5x2.5"" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
• Extras - Tubeless kit (liquid, valves, levers, manual, tool)
• Lock - Torx 25 Battery Lock with built-in Torque limiter
• Weight - The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
