Key Performance Factors
Modern MTB Design
Tapered fork steerer tubes*, quality components like a 1x drivetrain* with a clutch-equipped rear derailleur, thru-axle hubs*, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails. (*select models)
Off-Road Control
The new geometry is optimized for confident trail riding, with two wheel size options (27.5- or 29-inch) based on frame size. It’s also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tires (up to 2.4 inches) for traction and grip on technical terrain.
Light and Durable
The all-new ALUXX aluminum frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications
- Sizes27.5: XS, S 29 S, M, L
- ColoursSatin Tyrian Purple/Good Grey, Gloss Golden Wheat
- FrameALUXX-grade aluminium, disc
- ForkSR Suntour XCE, QR, steel steerer XS&S: 80mm travel (27.5) S-L:100mm travel (29)
- ShockN/A
- HandlebarGiant Connect Trail, 31.8mm XS&S: 690mm (27.5) S-L: 750mm (29)
- StemGiant Sport, 7-degree rise
- SeatpostGiant Sport, 30.9mm
- SaddleLiv ErgoContact Trail
- PedalsMTB caged
- ShiftersShimano Altus, 2x8
- Front DerailleurShimano Acera
- Rear DerailleurShimano Altus
- BrakesTektro HDC TKD 149, hydraulic, Tektro rotors [F]180mm, [R]160mm
- Brake LeversTektro TKD 149, for small hands
- CassetteShimano Altus HG31, 11x34
- ChainKMC 8.3
- CranksetShimano Altus FC-M315, 22/36
- Bottom BracketVP cartridge
- RimsGiant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
- HubsAlloy, sealed bearing, [F] 9x100 QR, [R] 12x142 thru-axle
- Spokesstainless, 14g
- TyresMaxxis Ikon 27.5x2.2 or Maxxis Ikon 29x2.2, wire bead
- Extras-
- Max Tyre Clearance2.4"
Every effort has been made to ensure accuracy throughout this website. However, Giant reserves the right to change bike specifications, features, prices and colours without prior notice.
Highlights
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- S (29")
- 158 cm
169 cm
- M (29")
- 164 cm 175 cm
- L (29")
- 170 cm 181 cm
- XS (27.5")
- 150 cm 163 cm
- S (27.5")
- 158 cm 169 cm
