Reliable mountain bike hardtail for any terrain. Revox frame with updated geometry and bigger size range, more tyre clearance and improved compatibility when retrofitting fenders and kickstand.
-
- Frame
- 29" (27.5"), lite AL-6061 tubing
- Fork
- Suntour XCE28 DS, 100 mm, preload adjust
- Rear Derailleur
- Shimano RD-TX800
- Front Derailleur
- Shimano FD-TY700
- Shifters
- Shimano SL-M315, 3x8-speed, rapidfire-plus-shifter
- Crankset
- Shimano FC-TY501, 42/34/24t
- BB-Set
- Sealed cartridge, BSA
- Chain
- KMC Z8
- Cassette
- Sunrace CS-M55, 11-34t
- Brake Levers
- Shimano BL-MT200, hydraulic disc brake
- Brakes
- Shimano BR-MT200, hydraulic disc brake
- Rotor
- Shimano SM-RT10, 160 mm
- Handlebar
- BGM Comp, riserbar, width: 700 mm
- H'stem
- BGM Comp, +/-6°
- Seatpost
- BGM Comp
- Seat
- Syncros Tofino 2.5
- Headset
- BGM FP-H807B, A-Headset, semi-integrated, 1 1/8"
- Hub (Front)
- Shimano, centerlock, disc, quick release
- Hub (Rear)
- Shimano, centerlock, disc, quick release
- Spokes
- steel, black
- Rims
- Alex X20, disc, width: 20 mm
- Front Tire
- Kenda Booster, 29x2.40" (27.5x2.40")
- Tube: Impac SV29
- Rear Tire
- Kenda Booster, 29x2.40" (27.5x2.40")
- Tube: Impac SV27
- Pedals
- Feimin FP-803
- Approx weight in KG
- 14,6
- Color
- olive black (matt)
- Frame size
- XS7/S7/M7/M9/L9/XL9/XXL9
- Grips
- Syncros MTB
- Max. System Weight
- 115,0 kg
- The overall weight includes the bike, the rider, the equipment and possible additional luggage.
