KEY PERFORMANCE FACTORS
Powerful and responsive
SyncDrive Pro motor with 85Nm of torque creates powerful pedalling assistance even at low speeds. Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.
Adaptable to the terrain
Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
Clean cockpit
RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.
SPECIFICATIONS
- MotorGiant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
- BatteryGiant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
- ChargerGiant EnergyPak 6A smart charger, 60% in 3:00h
- ControllerGiant RideControl Ergo3, grip integrated remote
- DisplayGiant RideControl GO, frame integrated LED console Optional wireless ANT+ display
- SizesS, M, L, XL
- ColoursGloss Carbon Smoke/ Matte Carbon Smoke
- FrameAdvanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
- ForkFox 36 Float Performance E-Tuned, 29er, 150mm travel, 44mm offset, Grip 3-position Micro Adjust damper, Kabolt-X 110
- ShockFox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
- HandlebarGiant Contact 35 Trail, 35x780mm
- StemGiant Contact SL 35
- SeatpostGiant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
- SaddleGiant Romero, Neutral
- PedalsFlatpedal
- ShiftersShimano Deore SLX
- Front DerailleurMRP HD2 co-moulded chain guide
- Rear DerailleurShimano Deore SLX, 12-speed, Shadow+
- BrakesShimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm
- Brake LeversShimano SLX, I-spec EV
- CassetteShimano CS-M6100, 10-51T, 12-speed
- ChainKMC e.12 Sport, NP/NP, e-bike optimised
- CranksetPraxis Wave 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)
- Bottom Bracketn/a
- RimsGiant AM 29", Tubeless ready, 30mm inner width, e-bike optimised
- HubsShimano MT410, Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
- SpokesSapim E-Lite [R] Race [F], e-bike optimised
- TyresMaxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F] Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
- ExtrasTubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
Every effort has been made to ensure accuracy throughout this website. However, Giant reserves the right to change bike specifications, features, prices and colours without prior notice.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- S
- 163 cm
174 cm
- M
- 171 cm 182 cm
- L
- 179 cm 190 cm
- XL
- 187 cm 198 cm
